100-120TPH Granite Crusher Plant In Nigeria

100-120TPH Granite Crusher Plant Information

Material: Granite
Capacity: 100-200TPH
Customer mine Country: Nigeria
Feeding size: <500mm
Output size: 0-6mm, 6-12mm,12-19mm,19-25mm

Flowchart of 100-120TPH Granite Crusher Plant

Nigeria 100-120tph flowchart of complete sets of crushing equipment
Nigeria 100-120tph flowchart of complete sets of crushing equipment



100-120TPH Granite Crusher Plant Equipment List
1. Vibrating Grizzly Feeder: DN490*95
2. Primary jaw crusher: PE-600×900
3. Secondary Compound Cone Crusher with hydraulic oil station: DN1200
4. Circle Vibrating Screen: 4YD2160
5. Belt conveyor with 20 meters long. (transport from primary jaw crusher PE-600×900 to
Compound Cone Crusher DN1200)
6. Belt conveyor with 15 meters long (transport from Compound Cone Crusher DN1200 to Circle Vibrating Screen: 4YD2160)
7. Belt conveyor with 15 meters long (product output under the Circle Vibrating Screen 4YD1860)
8. Belt conveyor with 21 meters long (transport from Circle Vibrating Screen 4YD1860 to Compound Cone Crusher DN1200 for re-crushing)
9. Electric control cabinet

Notes:
1. Services (installation, test run, training):
The supplier can provide basic drawings and schematic drawings of equipment installation. The domestic technicians will be provided for free to guide installation and debugging, and the buyer will provide technicians with room and board. The buyer shall prepare the necessary auxiliary materials for installation.

2. Quality guarantee:
The equipment is guaranteed for one year. In the warranty period, due to the quality of the product manufacturing, manufacturers free warranty (except wearing parts).
